Supply voltage (min) (V)
1.65
Supply voltage (max) (V)
5.5
Number of channels
Number of Channels refers to the number of independent signal paths within an electronic component. It indicates how many separate signals can be processed or transmitted simultaneously. For example, an audio amplifier with two channels can amplify two separate audio signals, while a multi-channel data converter can convert multiple analog signals into digital data. The number of channels is a crucial parameter for determining the component's functionality and application.
2
Supply current (max) (μA)
10
Input type
Input Type refers to the type of signal that an electronic component can accept as input.
Standard CMOS
Output type
Output type refers to the type of signal or power that an electronic component can produce. It can be analog or digital, AC or DC, and can vary in voltage, current, or power levels. The output type is determined by the component's design and is crucial for matching it with other components in a circuit. Understanding the output type ensures proper signal processing, power delivery, and overall system functionality.
Push-Pull
Features
Balanced outputs
Operating temperature range (°C)
-40 to 125
This dual inverter is designed for 1.65-V to 5.5-V VCCoperation.
The SN74LVC2GU04-Q1 device contains two inverters with unbuffered outputs and performsthe Boolean function Y = A.
